Monel 400 forged fittings are top-notch piping components crafted for tough industrial settings where corrosion is a major concern. Made from a nickel-copper alloy, these fittings deliver remarkable strength, durability, and resistance to corrosion across a variety of temperatures. Thanks to their forged construction, they boast excellent structural integrity, precise dimensions, and a long lifespan even under high pressure. Monel 400 is particularly celebrated for its outstanding performance in marine, chemical, and acidic environments. These fittings are a go-to choice in critical piping systems where reliability, safety, and long-lasting performance are a must.
Monel 400 is mainly made up of nickel and copper, with small amounts of iron, manganese, and silicon added in. This special blend gives it impressive resistance to corrosion, including pitting and stress corrosion cracking. Monel 400 forged fittings showcase high tensile and yield strength, excellent toughness, and good fatigue resistance. They maintain their mechanical stability across a wide temperature range and perform reliably under high pressure, thermal stress, and challenging operating conditions.
| Standard | ASTM B564 / ASME SB564 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yousef Metals, one of the leading suppliers of Monel 400 Forged Fittings in Doha, Qatar, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Yousef Metals has established itself as a trusted name for premium stainless steel products across the Qatar.
Yes, we provide custom sizes of Monel 400 Forged Fittings to match your exact project requirements. At Yousef Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@yousefmetals.com.
Monel 400 forged fittings are commonly found in industries that demand exceptional corrosion resistance and mechanical strength. You’ll often see them in oil and gas processing, offshore and marine systems, chemical and petrochemical plants, heat exchangers, and desalination facilities. They’re also utilized in power generation and aerospace applications. These fittings are particularly well-suited for piping systems that come into contact with seawater, acidic, alkaline, and high-temperature environments, ensuring leak-free connections, minimizing maintenance, and providing long-term operational reliability.
